MTH6 Digital Tachometer and Hourmeter With Adjustable Overspeed Set Point
数字式速度表/小时表
,带可调超速开关点
This microprocessor-based digital tachometer and hourmeter with a built-in overspeed switch is highly accurate and dependable. It measures speed and running hours and can give an alarm or shut down the engine on overspeed.
![](vibrpic/vibe_time_over_MTH6.jpg)
The MTH6 case is polycarbonate, and its dial measures 3-1/2 in. (89 mm) in diameter. RPM data for the tachometer and overspeed switch is supplied by a magnetic pickup or battery charging alternator.
![](vibrpic/MTH-96115B_Page_1.jpg)
Features:
- Tachometer and hourmeter with overspeed shutdown or alarm switch
- 3-1/2 inches (89 mm) diameter dial
- Reads rpm data from a magnetic pickup or battery charging alternator
- Powered by 8 to 40 VDC
- Large 5-digit LCD display
- Maintains hours count when power is lost
- Front panel programming
- Hours can be reset to zero
![](vibrpic/MTH-96115B_Page_2.jpg)
|
